Manufacturer: Extreme Networks, Inc
Manufacturer Part Number: 412048MW4Y
Manufacturer Website Address: http://www.extremenetworks.com
Brand Name: Extreme Networks
Product Series: 4000
Product Model: 4120-48MW-4Y
Product Name: 48-port Multi-Gig 90W PoE Switch 48MW-4Y
Marketing Information:
ExtremeCloud IQ Managed Switching for the Wired Edge
The 4000 Series are ExtremeCloud IQ managed Layer 2 switches that simplify network operations while delivering all the power and flexibility of a traditional enterprise access switch. As a fully cloud-managed solution, the 4000 Series is ideal for enterprises looking for easy-to-manage, cost-effective Ethernet connectivity for their campus, branch or distributed sites.
4000 Series cloud management combines instant actions along with centralized visibility that simplify switch deployment, provisioning, and troubleshooting. Machine learning tools help quickly isolate issues, continuous cloud-delivery ensures latest management feature updates, and zero-touch provisioning allows rapid deployment across sites.
With 90W PoE, multi-gigabit access, stacking and policy services, the 4000 Series is a switch platform capable of addressing the evolving connectivity requirements of today’s and tomorrow’s wired edge.
The 4000 Series consists of 4120 and 4220 model families:
The 4120 family is comprised of a 24-port and a 48-port model, both with multigigabit (1/2.5Gb) and 90W PoE support across all access ports, and high-speed 4 x 10/25Gb uplink plus 2 x 100Gb uplink/stack ports, making it ideal as a wired concentrator for high-density Wi-Fi/IoT environments.
The 4220 family includes 8, 12, 24, and 48-port models with gigabit and multi-gigabit (1/2.5/5Gb) access ports, up to 90W PoE, and 4 x SFP+ uplink/stack ports and is a highly flexible enterprise Layer 2 wired edge solution.
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 48
Network (RJ-45): Yes
Uplink Port: Yes
Modular: Yes
Stack Port: Yes
Port/Expansion Slot Details:
- 48 x 2.5 Gigabit Ethernet Network
- 4 x 25 Gigabit Ethernet Expansion Slot
- 2 x 100 Gigabit Ethernet Stack
Media & Performance
Media Type Supported:
- Twisted Pair
- Optical Fiber
Ethernet Technology:
- 2.5 Gigabit Ethernet
- 25 Gigabit Ethernet
- 100 Gigabit Ethernet
Network Technology:
- 2.5GBase-T
- 25GBase-X
- 100GBase-X
I/O Expansions
Number of Total Expansion Slots: 6
Expansion Slot Type:
- SFP28
- QSFP28
Network & Communication
Layer Supported: 2
Networking Standards:
- IEEE 802.3at
- IEEE 802.3bt
- IEEE 802.1x
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.1ab
- IEEE 802.3ad
- IEEE 802.3ab
- IEEE 802.3
- IEEE 802.3bz
- IEEE 802.3ae
- IEEE 802.3by
- IEEE 802.3ba
- IEEE 802.3bm
- IEEE 802.3az
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: Yes
PoE Budget: 90 W
Input Voltage:
- 120 V AC
- 230 V AC
Power Source: Power Supply
Physical Characteristics
Form Factor: Rack-mountable
Height: 1.7″
Width: 17.4″
Depth: 13″
Weight (Approximate): 12.40 lb
