UfiSpace S9601-102XC 96x25G SFP28 Ports Aggregation Router

MFR# S9601-102XC
Authorized Dealer
Check availability

Request Pricing
?

B2B Pricing

Shop with confidence knowing that you have a dedicated B2B account team ready to answer any technical or sales questions.

  • Exclusive business pricing
  • Custom quotes
  • Responsive technical support
  • Pre-sales and after-sales support
Request a Quote
Add to Quote Cart
Brand: UfiSpace
Product Type: Aggregation Router
Main Port Count: 96 Ports
Main Port Type: SFP28
Main Port Speed: 25GbE
Product Brief: S9601-102XC

UfiSpace S9601-102XC 96x25G SFP28 Ports Aggregation Router, 2RU, 96x25GbE SFP28 ports, 6x100GbE QSFP28 ports, Broadcom Qumran2c BCM88820 ASIC, Intel Ice Lake D, 8 Cores, 2.1GHz (Standard) or 16 Cores, 2.0GHz (Premium) Processor, Dual AC or DC PSU

Ask a Product Specialist

Open networking requires the right combination of hardware, software, and support to succeed. Our in-house engineering and support team works closely with industry-leading partners to help you source and integrate the right components, validate designs, and deploy with confidence, backed by two decades of successful deployments for data centers, service providers, and enterprises.

Looking for something else or have a question about this product?
800.398.1262  |  Email
Get a Quote
Overview

The UfiSpace S9601-102XC is a 2RU open aggregation router based on the Broadcom Qumran2c ASIC with 96 25G SFP28 service ports and six 100G QSFP28 interfaces for service provider networks.

Use Cases

  • Service provider transport
  • Metro and mobile network routing

Ports & Switching

  • 96x25GbE SFP28 ports
  • 6x100GbE QSFP28 ports
  • Two additional 10G SFP+ management interfaces

Hardware & Platform

  • Broadcom Qumran2c BCM88820 silicon
  • Intel Ice Lake D, 8 Cores, 2.1GHz (Standard) or 16 Cores, 2.0GHz (Premium)
  • 64GB DDR4 system memory
  • 2x256GB SSD
  • 2RU rack form factor
  • 33.49 lbs (without FRU)

Cooling & Power

  • Dual AC or DC PSU
  • 3+1 hot-swappable fan units

Efficiency & Reliability

  • SyncE and IEEE 1588v2 timing
  • Class C synchronization
  • BMC for equipment health monitoring
  • Segment routing capabilities depend on the selected NOS
  • 4GB deep packet buffer
  • External Broadcom OP2 BCM16K TCAM

Ordering Information

  • S9601-102XC platform. Confirm the quoted configuration.
Specifications
Product Type

Aggregation Router
Main Port Count

96 Ports
Main Port Type

SFP28
Main Port Speed

25GbE
Uplink Port Count

6 Ports
Uplink Port Type

QSFP28
Uplink Port Speed

100GbE
ASIC

Broadcom Qumran2c BCM88820
Processor

Intel Ice Lake D, 8 Cores, 2.1GHz (Standard) or 16 Cores, 2.0GHz (Premium)
Flash Memory

2x256GB SSD
Power Supply

Dual PSU
Weight

33.49 lbs
Frequently Asked Questions

Question:

What ports does the S9601-102XC have?
Hardware Nation
12-Oct-2026

Answer:

96x25G ports and six 100G ports in a 2RU chassis.

Question:

What switch chip does it use?
Hardware Nation
12-Oct-2026

Answer:

Broadcom Qumran2c, BCM88820, with an external Broadcom OP2 TCAM and a 4 GB deep packet buffer.

Question:

What is it designed for?
Hardware Nation
12-Oct-2026

Answer:

Mobile fronthaul and backhaul aggregation, metro aggregation or broadband network gateway deployments, with the appropriate routing software.

Question:

Does it support network timing?
Hardware Nation
12-Oct-2026

Answer:

Its hardware supports SyncE and IEEE 1588v2 PTP with Class C timing, plus GNSS and external timing interfaces. The selected NOS must implement the required timing profile.

Question:

Does it have redundant power and cooling?
Hardware Nation
12-Oct-2026

Answer:

Yes. Two hot-swappable power supplies provide 1+1 redundancy, and four hot-swappable fan modules provide 3+1 redundancy. AC and DC power options are available.

Question:

What CPU, memory and storage does it have?
Hardware Nation
12-Oct-2026

Answer:

Intel Ice Lake-D: eight cores at 2.1 GHz in Standard, or 16 cores at 2.0 GHz in Premium. Both configurations have 64 GB DDR4 memory and two 256 GB SSDs.

Question:

How is it different from the S9600-102XC?
Hardware Nation
12-Oct-2026

Answer:

Both provide 96x25G and six 100G ports using Qumran2c. The S9600-102XC has an eight-core Skylake-D CPU, 32 GB RAM and 128 GB storage; the S9601-102XC uses Ice Lake-D, 64 GB RAM and two 256 GB SSDs, with Standard and Premium CPU choices.
