UfiSpace S7801-54XS 48x10G SFP+ Ports Leaf Switch

MFR# S7801-54XS
Authorized Dealer
Check availability

Request Pricing
?

B2B Pricing

Shop with confidence knowing that you have a dedicated B2B account team ready to answer any technical or sales questions.

  • Exclusive business pricing
  • Custom quotes
  • Responsive technical support
  • Pre-sales and after-sales support
Request a Quote
Add to Quote Cart
Brand: UfiSpace
Product Type: Open Switches
Main Port Count: 48 Ports
Main Port Type: SFP+
Main Port Speed: 10GbE
Product Brief: S7801-54XS

UfiSpace S7801-54XS 48x10G SFP+ Ports Leaf Switch, 1RU, 48x10GbE SFP+ ports, 6x100GbE QSFP28 ports, Broadcom Trident 3 X5 BCM56771 ASIC, Intel Denverton, 4 Cores, 1.6GHz Processor, Dual AC or DC PSU, Supported NOS SONiC

Ask a Product Specialist

Open networking requires the right combination of hardware, software, and support to succeed. Our in-house engineering and support team works closely with industry-leading partners to help you source and integrate the right components, validate designs, and deploy with confidence, backed by two decades of successful deployments for data centers, service providers, and enterprises.

Looking for something else or have a question about this product?
800.398.1262  |  Email
Get a Quote
Overview

The UfiSpace S7801-54XS is a 1RU 10G data center leaf switch based on the Broadcom Trident 3 X5 ASIC with 48 SFP+ access ports and six 100G QSFP28 uplinks.

Use Cases

  • Data center Ethernet connectivity
  • Cloud and AI infrastructure

Ports & Switching

  • 48x10GbE SFP+ ports
  • 6x100GbE QSFP28 ports
  • 48x1G/10G access interfaces and 6x40G/100G uplinks

Hardware & Platform

  • Broadcom Trident 3 X5 BCM56771 silicon
  • Intel Denverton, 4 Cores, 1.6GHz
  • 8GB DDR4, expandable to 32GB system memory
  • 32GB SSD
  • 1RU rack form factor
  • 17.32 x 17.32 x 1.72 in (W x D x H)
  • 19.62 lbs (without FRU)

Compatible Software (NOS)

  • Open Network Install Environment (ONIE)
  • Compatible with SONiC
  • Software licensing and the supported feature set depend on the selected NOS and configuration.

Cooling & Power

  • Dual AC or DC PSU
  • 4+1 hot-swappable fan units

Efficiency & Reliability

  • Front-to-back or back-to-front airflow options
  • AST2620 BMC

Ordering Information

  • S7801-54XS platform. Confirm the quoted configuration.
Specifications
Product Type

Open Switches
Main Port Count

48 Ports
Main Port Type

SFP+
Main Port Speed

10GbE
Uplink Port Count

6 Ports
Uplink Port Type

QSFP28
Uplink Port Speed

100GbE
ASIC

Broadcom Trident 3 X5 BCM56771
Processor

Intel Denverton, 4 Cores, 1.6GHz
Flash Memory

32GB SSD
Power Supply

Dual PSU
Supported NOS

SONiC
Software

Open Network Install Environment (ONIE)
Dimensions

17.32 x 17.32 x 1.72 in
Weight

19.62 lbs
Frequently Asked Questions

Question:

Which network operating systems can I run on the S7801-54XS?
Hardware Nation
12-Oct-2026

Answer:

Community SONiC and Enterprise SONiC Distribution by Broadcom are supported options. Use the image qualified for this exact platform and the required features; commercial licensing and support are separate from hardware compatibility. Other NOS options may be available as the ecosystem evolves.

Question:

What ports does the S7801-54XS have?
Hardware Nation
12-Oct-2026

Answer:

48x10G SFP+ ports and six 100G QSFP28 ports in a 1RU chassis.

Question:

What switch chip does it use?
Hardware Nation
12-Oct-2026

Answer:

Broadcom Trident 3-X5, BCM56771.

Question:

What is it designed for?
Hardware Nation
12-Oct-2026

Answer:

A data center access or leaf role, with 10G-facing connections and 100G uplinks.

Question:

What airflow and power options does it have?
Hardware Nation
12-Oct-2026

Answer:

Front-to-back and back-to-front airflow configurations, with AC or DC PSU options. Power supplies provide 1+1 redundancy, and five hot-swappable fans provide 4+1 redundancy.

Question:

What CPU, memory and storage does it have?
Hardware Nation
12-Oct-2026

Answer:

A quad-core Intel Denverton processor at 1.6 GHz, 8 GB DDR4 memory with support for up to 32 GB, and 32 GB SSD storage.

Question:

Can I monitor its hardware remotely?
Hardware Nation
12-Oct-2026

Answer:

Yes. An AST2620 BMC provides remote hardware monitoring and management.
Warranty
All new products are covered by the manufacturer warranty. To claim warranty, you may contact the manufacturer directly or contact your account executive at Hardware Nation. We can help facilitate the warranty processes between the customer and manufacturer.
