UfiSpace M3000-14XC Fronthaul Multiplexer

MFR# M3000-14XC
Authorized Dealer
Check availability

Request Pricing
?

B2B Pricing

Shop with confidence knowing that you have a dedicated B2B account team ready to answer any technical or sales questions.

  • Exclusive business pricing
  • Custom quotes
  • Responsive technical support
  • Pre-sales and after-sales support
Request a Quote
Add to Quote Cart
Brand: UfiSpace
Product Type: Fronthaul Multiplexer
Main Port Count: 12 Ports
Main Port Type: SFP+
Main Port Speed: 10GbE
Product Brief: M3000-14XC

UfiSpace M3000-14XC Fronthaul Multiplexer, 1RU, 8 Radio-Facing and 1 Active DU-Facing 10G Interfaces, ARM Cortex-A53 Quad-Core Processor, Intel Stratix 10 TX FPGA, Dual AC or DC Power Supplies, SyncE and IEEE 1588v2 Timing

Ask a Product Specialist

Open networking requires the right combination of hardware, software, and support to succeed. Our in-house engineering and support team works closely with industry-leading partners to validate designs, integrate hardware and software, and coordinate support across vendors, so you don’t have to piece it all together yourself. We bring over a decade of successful deployments for data centers, service providers, and enterprises.

Looking for something else or have a question about this product?
800.398.1262  |  Email
Get a Quote
Overview

The UfiSpace M3000-14XC is a 1RU O-RAN fronthaul multiplexer based on the Intel S10-TX FPGA that aggregates radio connections and enables distributed unit resources to be shared across them.

Use Cases

  • O-RAN fronthaul
  • Private 5G distribution unit resource sharing

Ports & Switching

  • 12 physical SFP+ cages with eight radio-facing and one active DU-facing 10G port
  • Two reserved 100G QSFP28 cages
  • Eight 10G radio-facing ports and one active 10G DU-facing port
  • Three additional DU-facing ports reserved in the published configuration
  • Two 100G QSFP28 ports reserved in the reviewed datasheet

Hardware & Platform

  • Intel S10-TX FPGA silicon
  • ARM Cortex-A53, 4 Cores, 1.0GHz
  • 4GB DDR4 system memory
  • 1RU rack form factor
  • 17.32 x 9.84 x 1.71 in (W x D x H)
  • 9.22 lbs (without FRU)

Cooling & Power

  • Dual AC or DC PSU
  • 4 fixed fans

Efficiency & Reliability

  • SyncE and IEEE 1588v2 timing
  • CLI, SNMP and NETCONF management

Ordering Information

  • M3000-14XC platform with redundant AC or DC power units
  • Datasheet marks GNSS as a future Premium function activated by a software license. Confirm timing configuration.
Specifications
Product Type

Fronthaul Multiplexer
Main Port Count

12 Ports
Main Port Type

SFP+
Main Port Speed

10GbE
ASIC

Intel S10-TX FPGA
Processor

ARM Cortex-A53, 4 Cores, 1.0GHz
Power Supply

Dual PSU
Dimensions

17.32 x 9.84 x 1.71 in
Weight

9.22 lbs
Frequently Asked Questions

Question:

What is the M3000-14XC used for?
Hardware Nation
12-Oct-2026

Answer:

It is a fronthaul multiplexer for O-RAN deployments. It groups radio units into a shared cell and supports Cascade-FHM operation to extend coverage while making more efficient use of distributed-unit resources.

Question:

What ports does it have?
Hardware Nation
12-Oct-2026

Answer:

Eight 10G SFP+ interfaces face the radio units, four 10G SFP+ interfaces face the distributed unit, and two 100G QSFP28 interfaces are reserved. The datasheet currently makes only DU port 8 available; DU ports 9–11 are reserved.

Question:

What processor and FPGA does it use?
Hardware Nation
12-Oct-2026

Answer:

A quad-core ARM Cortex-A53 processor at 1.0 GHz and an Intel S10-TX FPGA, with 4 GB DDR4 memory.

Question:

Does it support fronthaul timing?
Hardware Nation
12-Oct-2026

Answer:

It supports SyncE and IEEE 1588v2 timing. GNSS and some timing modes depend on the Premium version and software licensing, so they should not be assumed on every configuration.

Question:

Is it suitable for outdoor cabinets?
Hardware Nation
12-Oct-2026

Answer:

Its operating temperature range is −40°C to 70°C, and its 1RU chassis is 250 mm deep. It is intended for installation in a suitable cabinet; this temperature rating is not an enclosure weatherproofing rating.

Question:

Does it have redundant power?
Hardware Nation
12-Oct-2026

Answer:

Yes. It uses hot-swappable power supplies with 1+1 redundancy. AC and DC PSU options are available, and the cooling uses four fixed fans.

Question:

How do I manage it?
Hardware Nation
12-Oct-2026

Answer:

Through CLI, SNMP or NETCONF. It also provides RJ45 management and serial-console interfaces.
