Edge-Core AMX3200 AMX3200-O-AC-F 16x100G QSFP28 Ports Coherent Transponder and Muxponder AC Power

MFR# AMX3200-O-AC-F
Authorized Dealer
Check availability

Request Pricing
?

B2B Pricing

Shop with confidence knowing that you have a dedicated B2B account team ready to answer any technical or sales questions.

  • Exclusive business pricing
  • Custom quotes
  • Responsive technical support
  • Pre-sales and after-sales support
Request a Quote
Add to Quote Cart
Brand Name: Edge-Core
Product Type: Coherent Transponder and Muxponder
Main Port Count: 16 Ports
Main Port Type: QSFP28
Main Port Speed: 100GbE
Product Brief: AMX3200-O-AC-F

Edge-Core AMX3200 AMX3200-O-AC-F 16x100G QSFP28 Ports Coherent Transponder and Muxponder AC Power, 1RU, 16x100GbE QSFP28 ports, Intel Atom C3508 Processor, Dual 1200W AC PSU, Front-to-back airflow, Supported NOS NEC NOS

Ask a Product Specialist

Open networking requires the right combination of hardware, software, and support to succeed. Our in-house engineering and support team works closely with industry-leading partners to validate designs, integrate hardware and software, and coordinate support across vendors, so you don’t have to piece it all together yourself. We bring over a decade of successful deployments for data centers, service providers, and enterprises.

Looking for something else or have a question about this product?
800.398.1262  |  Email
Get a Quote
Overview

The Edgecore AMX3200-O-AC-F is a 1RU coherent transponder and muxponder that connects Ethernet client interfaces to optical line interfaces through two modular sleds for data center and metro transport. This configuration includes dual 1200W AC power supplies and front-to-back airflow.

Use Cases

  • Data center interconnect
  • Metro and service provider optical transport

Ports & Switching

  • 16x100GbE QSFP28 ports
  • Two modular sleds, each with eight client and two line interfaces
  • IEEE 1588v2 timing support
  • Four CFP2-DCO coherent optical line interfaces at up to 400G with both sleds installed

Hardware & Platform

  • Intel Atom C3508
  • 8GB DDR4, expandable to 16GB system memory
  • 2x16MB SPI flash; 128GB M.2 SSD
  • 1RU rack form factor
  • 17.26 x 16.93 x 1.71 in (W x D x H)
  • 22.66 lbs (with 2 sleds, 2 PSUs and 5 fans)

Compatible Software (NOS)

  • Open Network Install Environment (ONIE)
  • Compatible with NEC NOS
  • Software licensing and the supported feature set depend on the selected NOS and configuration.

Cooling & Power

  • Dual 1200W AC PSU
  • Front-to-back airflow
  • 4+1 hot-swappable fans

Efficiency & Reliability

  • 100G, 200G, 300G and 400G coherent line rates
  • OIF400ZR, OpenZR+ and OpenROADM interoperability

Ordering Information

  • AMX3200-O-AC-F with dual 1200W AC PSU and front-to-back airflow
  • Confirm the power cord for the destination country when ordering.
  • Confirm included sleds and optical modules for the quote.
  • Other configuration AMX3200-O-48V-F with dual 1200W DC PSU and front-to-back airflow
Specifications
Brand Name

Edge-Core
Product Type

Coherent Transponder and Muxponder
Main Port Count

16 Ports
Main Port Type

QSFP28
Main Port Speed

100GbE
Processor

Intel Atom C3508
Flash Memory

2x16MB SPI flash; 128GB M.2 SSD
Power Supply

Dual PSU
Supported NOS

NEC NOS
Software

Open Network Install Environment (ONIE)
Dimensions

17.26 x 16.93 x 1.71 in
Weight

22.66 lbs
Frequently Asked Questions

Question:

Which network operating systems can I run on the AMX3200-O-AC-F?
Hardware Nation
12-Oct-2026

Answer:

NEC NOS is a software option for the AMX3200. It is an open optical transport platform, so its software must control the coherent line interfaces and transponder functions. Other NOS options may be available as the ecosystem evolves.

Question:

Is the AMX3200 an Ethernet switch or an optical transport system?
Hardware Nation
12-Oct-2026

Answer:

It is a 1RU coherent transponder and muxponder for optical transport. It combines client connections onto coherent line-side links rather than acting as an ordinary leaf or spine Ethernet switch.

Question:

How many client and line ports does it have?
Hardware Nation
12-Oct-2026

Answer:

Each sled has eight 40G/100G QSFP+/QSFP28 client ports and two 400G CFP2-DCO line ports. A fully populated two-sled chassis has 16 client ports and four line ports.

Question:

Which coherent optical standards does it support?
Hardware Nation
12-Oct-2026

Answer:

OIF 400ZR, OpenZR+ and OpenROADM. The usable line rate and reach depend on the selected coherent module and the optical link design.

Question:

What power and airflow does this version use?
Hardware Nation
12-Oct-2026

Answer:

AMX3200-O-AC-F uses AC power supplies with front-to-back airflow. The PSUs are hot-swappable and load-sharing with 1+1 redundancy.

Question:

Does it have redundant cooling?
Hardware Nation
12-Oct-2026

Answer:

Yes. It has five hot-swappable fan modules in a 4+1 redundant arrangement.

Question:

What CPU, memory and storage does it have?
Hardware Nation
12-Oct-2026

Answer:

An Intel Atom C3508 CPU, 8 GB DDR4 memory with support for up to 16 GB, and 128 GB SSD storage.

Question:

Can I assume every 400G optic will work in it?
Hardware Nation
12-Oct-2026

Answer:

No. The client side uses QSFP+/QSFP28 modules and the coherent line side uses CFP2-DCO modules. Module type, supported line mode and optical link requirements must match the transport configuration.
Warranty
All new products are covered by the manufacturer warranty. To claim warranty, you may contact the manufacturer directly or contact your account executive at Hardware Nation. We can help facilitate the warranty processes between the customer and manufacturer.
